Shelly Pro Dimmer 0/1-10 V PM

The Shelly Pro Dimmer 0/1-10V PM is a professional single-channel DIN rail-mountable controller designed for smart management of LED drivers and ballasts supporting the 0/1-10V analog dimming protocol. As part of the Pro series, it provides maximum reliability for industrial and commercial installations through its LAN (Ethernet) port, ensuring a stable connection independent of Wi-Fi stability.

This device enables smooth, flicker-free dimming while simultaneously monitoring energy consumption via its integrated power metering feature. The internal relay allows for complete power cut-off to the load, effectively eliminating standby power draw from connected drivers. It supports advanced local scripting and webhooks for tailored automation logic.

• Triple Connectivity: Integrated LAN, Wi-Fi, and Bluetooth for redundant and flexible networking.

• Analog Signal Management: Compatible with both 0-10V and 1-10V ballast and driver systems.

• Power Metering (PM): Real-time energy monitoring for operational efficiency and cost tracking.

• DIN Rail Mountable: Compact 1-module design for seamless integration into professional electrical panels.

Technical Specifications:

• Power Supply: 110 - 240V AC.

• Signal Output: 0-10V / 1-10V DC (max 35mA).

• Relay Output: 1 channel (max 10A).

• Energy Monitoring: Yes (W, V, A).

• Communication: LAN (RJ45), Wi-Fi 802.11 b/g/n, Bluetooth 4.2.

• Safety Features: Built-in protection against overheating, overload, and overvoltage.

• Dimensions: 94 x 19 x 69 mm (1 DIN module).
