Features:
Controlling road barriers in the yards of blocks of flats or offices.
Opening personal house gates
Turning on an electronic device for a specified period. (aquarium lighting, turning on the pump, watering, controlling heating in premises etc).
Turning on the system.
Turning on any electric device controlled with using ON/OFF function.
Rebooting “frozen” system, (computer network or server).
Notification about a fault in gate or other automatics device.
TechInfo: Supply voltage: 10-24V ~ 200mA max or 10-24V DC 200mA max;
Current used in standby model: not more than 50mA;
GSM modem frequency: 900/1800 Mhz
Number of outputs: 1;
Output type: NO (relay);
Number of “low” level (negative) inputs: 2;
Number of “high” level (positive) inputs: 1;
Allowable “low” level (negative) input voltage values: 0-1.6V;
Allowable “high” level (positive) input voltage values: 5-50V;
C1 output maximum commutating values: 1A/24V DC; 0,5A/125V AC;
Dimensions: 70x85x57mm;
Operating temperature range: -20…+55oC (-30...+55oC with limitations);
Number of administrators: 5;
Number of users: 500;
