Dimming actuator (refurbished)

Connects to an existing system and turns on lights when tripped. It has 3 modes of operation:
In mode 1 the SM10 will turn On all Lamp Modules and Wall Switch Modules set to its House code, and will also turn On any other Modules set to its Unit code, a stereo connected to an Appliance Module, for example. All Lamp Modules and Wall Switch Module are left in the On state when the system is deactivated, but the Module set to the same Unit code as the SM10 will turn Off.
In mode 2 the SM10 will FLASH all lights connected to Lamp Modules or Wall Switch Modules. All Lamp and Wall Switch Modules will be left in the On state when the system is de-activated but Appliance modules set to the same House code as the SM10 will turn Off.
In mode 3 the SM10 will turn ON any Module set to the same House Code and Unit Code as the SM10 when the system is activated and turns it OFF when the input contact is opened.
Set the input switch to A for triggering the interface by a low voltage input (6-8 V AC, DC or audio), to B for triggering the interface by a dry contact closure. Do not connect 220V to the input terminal!
The SM10 has a test button which allows you to activate it whether or not it is connected to a system. The All light off button allows you to turn off anything which has been turned on by the interface.
To install the SM10 (is expected to be installed inside the security controller panel) :
• Connect the system output to the screw terminals.
• Connect the flying lead to the 230V power supply, most likely at the 230V side of the transformer.

PowerHorn is used as an additional audio alarm unit for use with the Home Security System which gives an additional independent 110 decibel sound output when the security system is triggered. The PowerHorn will only trip a few seconds later after the alarm trips. It counts the sequence transmitted to flash lights connected to Lamp Modules after the lights have flashed 4 or 5 times. This prevents it from being accidentally tripped from any other X10 controller.
You can also trip the PowerHorn from any other X10 controller, which is useful in panic situations.
It can be added anywhere around the home; nobody wants to hang around when one of these activate.

The LMM32 module allow to dim two individual lamps, being small enough (43 x 47 x 18,9 mm) to fit behind a wall switch or junction box. It allows to control both internal relay either using any conventional electric switch (push buttons are not supported) or remotely, using any X-10 compatible controller.

This module has a special feature which allows setting 16 distinct X-10 addresses to each internal relay. This is very useful to create macros.

We would like to point out that this article is not a new product. The product has got the complete functionality and can be used without restriction. However, the product may have the following characteristics:

broken seal,
damaged packaging,
no original packaging
missing accessories,
minimal signs of wear,
no current software version.

We offer a guarantee of one year. With a possible return you receive a credit note, there is no exchange of the product. The picture may not correspond to the scope of delivery of the product.

This module was designed to control electric shutters or curtains.
X10 compatible.
